FRPP examples migrated from emhawkes

These three examples come from the flexible-residual section of emhawkes’s Extended examples. Kernel parameters and output sizes are unchanged. The complete original emhawkes code, including its custom fitting objective, is preserved in Legacy emhawkes FRPP examples. FRPP-specific functionality is planned to move here; simple residual-law models remain supported by emhawkes during the transition.

Each simulation uses seed 1107 explicitly; the original one-dimensional and uniform examples inherited their random state from earlier examples. size includes the initial row. The initial component state is explicitly zero.

The model contains a kernel and a residual law. The default bridge simulator and likelihood reuse public emhawkes functions. These examples explicitly select the independent state simulator when its event-wise kernel APIs are installed, and report the selected backend. The state likelihood separately uses public kernel replay, excluding the baseline. Kernel components are driving quantities, rather than the conditional intensity of a general FRPP. All dimensions redraw candidate residuals after every event.

The optional state comparisons require the public shared-kernel API in GitHub development emhawkes 1.0.1.9000. When it is not installed, simulations and bridge likelihoods still run, and state comparisons are reported as unavailable rather than as successful checks.

One dimension: trapezoid-exponential residuals

tz_law <- residual_law(c(a = 0.7, ell = 1.6),
  dresidual = emhawkes::dtzexp, presidual = emhawkes::ptzexp,
  qresidual = emhawkes::qtzexp, rresidual = emhawkes::rtzexp, name = "tzexp")
model_1d <- fspec(
  methods::new("hspec", mu = 0.5, alpha = 1, beta = 1.2), tz_law)
set.seed(1107)
path_1d <- fsim(model_1d, size = 3000, lambda_component0 = 0, backend = simulation_backend)
seed_1d <- .Random.seed
inferred_1d <- logLik(model_1d, path_1d$inter_arrival,
  lambda_component0 = 0, infer = TRUE)
state_1d <- if (has_kernel_api) logLik(model_1d, path_1d$inter_arrival,
  lambda_component0 = 0, infer = TRUE, backend = "state") else NULL
c(bridge = inferred_1d$loglikelihood,
  state = if (has_kernel_api) state_1d$loglikelihood else NA_real_)
#>   bridge    state
#> 1114.393 1114.393

hist(inferred_1d$res_process1, breaks = 100, probability = TRUE,
  main = "One-dimensional FRPP residuals", xlab = "Residual")
curve(emhawkes::dtzexp(x, a = 0.7, ell = 1.6), add = TRUE, col = "red")

Two dimensions: trapezoid-exponential residuals

kernel_2d <- methods::new("hspec", mu = c(0.3, 0.3),
  alpha = matrix(c(0.5, 0.8, 0.8, 0.5), 2, byrow = TRUE),
  beta = matrix(1.5, 2, 2))
model_2d <- fspec(kernel_2d, tz_law)
set.seed(1107)
path_2d <- fsim(model_2d, size = 10000, lambda_component0 = 0, backend = simulation_backend)
seed_2d <- .Random.seed
inferred_2d <- logLik(model_2d, path_2d$inter_arrival, path_2d$type,
  lambda_component0 = 0, infer = TRUE)
state_2d <- if (has_kernel_api) logLik(model_2d, path_2d$inter_arrival, path_2d$type,
  lambda_component0 = 0, infer = TRUE, backend = "state") else NULL
c(bridge = inferred_2d$loglikelihood,
  state = if (has_kernel_api) state_2d$loglikelihood else NA_real_)
#>    bridge     state
#> -12413.76 -12413.76

hist(inferred_2d$res_process2, breaks = 50, probability = TRUE,
  main = "Two-dimensional FRPP residuals", xlab = "Residual")
curve(emhawkes::dtzexp(x, a = 0.7, ell = 1.6), add = TRUE, col = "red")

hist(inferred_2d$eres_process1, breaks = 50, probability = TRUE,
  main = "Exponential transformed residuals", xlab = "Transformed residual")
curve(stats::dexp(x), add = TRUE, col = "red")

Two dimensions: uniform residuals

uniform_law <- residual_law(c(min = 0, max = 2),
  stats::dunif, stats::punif, stats::qunif, stats::runif, name = "Uniform(0,2)")
model_uniform <- fspec(methods::new("hspec", mu = c(0.5, 0.5),
  alpha = matrix(0.3, 2, 2), beta = matrix(1.2, 2, 2)), uniform_law)
set.seed(1107)
path_uniform <- fsim(model_uniform, size = 5000, lambda_component0 = 0, backend = simulation_backend)
seed_uniform <- .Random.seed
inferred_uniform <- logLik(model_uniform, path_uniform$inter_arrival,
  path_uniform$type, lambda_component0 = 0, infer = TRUE)
state_uniform <- if (has_kernel_api) logLik(model_uniform, path_uniform$inter_arrival,
  path_uniform$type, lambda_component0 = 0, infer = TRUE, backend = "state") else NULL
c(bridge = inferred_uniform$loglikelihood,
  state = if (has_kernel_api) state_uniform$loglikelihood else NA_real_)
#>    bridge     state
#> -7287.486 -7287.486

hist(inferred_uniform$res_process1, breaks = 50, probability = TRUE,
  main = "Uniform FRPP residuals", xlab = "Residual")
curve(stats::dunif(x, 0, 2), add = TRUE, col = "red")

Compare the original and migrated examples

The reference objects below use the original representation. Compare every simulation field and the final RNG state exactly. The bridge must return the same inference result. Independent state calculations use a fixed numerical comparison tolerance of 1e-10; their absolute differences are also reported.

reference_1d <- emhawkes::set_residual(
  methods::new("hspec", mu = 0.5, alpha = 1, beta = 1.2),
  param = c(a = 0.7, ell = 1.6), dresidual = emhawkes::dtzexp,
  presidual = emhawkes::ptzexp, qresidual = emhawkes::qtzexp,
  rresidual = emhawkes::rtzexp)
reference_2d <- emhawkes::set_residual(
  methods::new("hspec", mu = c(0.3, 0.3),
    alpha = matrix(c(0.5, 0.8, 0.8, 0.5), 2, byrow = TRUE),
    beta = matrix(1.5, 2, 2)),
  param = c(a = 0.7, ell = 1.6), dresidual = emhawkes::dtzexp,
  presidual = emhawkes::ptzexp, qresidual = emhawkes::qtzexp,
  rresidual = emhawkes::rtzexp)
reference_uniform <- methods::new("hspec", mu = c(0.5, 0.5),
  alpha = matrix(0.3, 2, 2), beta = matrix(1.2, 2, 2),
  rresidual = function(size) runif(n = size, 0, 2),
  dresidual = function(x, param = numeric(0), log = FALSE) dunif(x, 0, 2, log = log),
  presidual = function(q, param = numeric(0), lower.tail = TRUE, log.p = FALSE)
    punif(q, 0, 2, lower.tail = lower.tail, log.p = log.p),
  qresidual = function(p, param = numeric(0), lower.tail = TRUE, log.p = FALSE)
    qunif(p, 0, 2, lower.tail = lower.tail, log.p = log.p))
compare_example <- function(reference, path, seed_after, bridge, state) {
  set.seed(1107)
  old <- emhawkes::hsim(reference, size = length(path$type), lambda_component0 = 0)
  fields <- setdiff(names(old), "hspec")
  stopifnot(identical(unclass(path)[fields], unclass(old)[fields]),
    identical(.Random.seed, seed_after))
  expected <- emhawkes::logLik(reference, old$inter_arrival, old$type,
    mark = old$mark, lambda_component0 = 0, infer = TRUE)
  stopifnot(identical(bridge, expected))
  shared <- names(expected)
  if (!is.null(state)) stopifnot(isTRUE(all.equal(state[shared], expected, tolerance = 1e-10)))
  data.frame(rows = length(path$type), simulation_backend = simulation_backend,
    simulation_exact = TRUE, rng_exact = TRUE,
    bridge_exact = TRUE,
    state_loglik_difference = if (is.null(state)) NA_real_ else state$loglikelihood - expected$loglikelihood,
    maximum_state_output_difference = if (is.null(state)) NA_real_ else max(vapply(shared, function(nm)
      if (length(expected[[nm]])) max(abs(state[[nm]] - expected[[nm]])) else 0,
      numeric(1))))
}
comparison <- rbind(
  tzexp_1d = compare_example(reference_1d, path_1d, seed_1d, inferred_1d, state_1d),
  tzexp_2d = compare_example(reference_2d, path_2d, seed_2d, inferred_2d, state_2d),
  uniform_2d = compare_example(reference_uniform, path_uniform, seed_uniform,
    inferred_uniform, state_uniform))
comparison
#>             rows simulation_backend simulation_exact rng_exact bridge_exact
#> tzexp_1d    3000              state             TRUE      TRUE         TRUE
#> tzexp_2d   10000              state             TRUE      TRUE         TRUE
#> uniform_2d  5000              state             TRUE      TRUE         TRUE
#>            state_loglik_difference maximum_state_output_difference
#> tzexp_1d             -7.048584e-12                    7.048584e-12
#> tzexp_2d              5.456968e-12                    5.456968e-12
#> uniform_2d            4.947651e-10                    4.947651e-10

Estimation with ffit

ffit() fits the new composition model. Residual parameters stay fixed by default; this example explicitly estimates them jointly. The same six shared parameters, initial state and constraints as the original example are used. No automatic scale normalization or Hawkes Hessian stabilization is applied.

A matched 10,000-row validation records the estimates, restoration, curvature diagnostics and elapsed times under explicitly matched optimizer controls.

The long fit is opt-in. Set FRPP_RUN_LONG_EXAMPLES=true before rendering this vignette to execute it; simulation and likelihood examples always run.

residual_valid <- function(param) tryCatch({
  emhawkes::dtzexp(1, a = param["a"], ell = param["ell"])
  TRUE
}, error = function(e) FALSE)
constraints <- list(ineqA = rbind(diag(6), c(0, 0, 0, 0, -1, 0)),
  ineqB = c(rep(0, 6), 3))

fit <- ffit(model_2d, path_2d$inter_arrival, path_2d$type,
  estimate_residual = TRUE, constraints = constraints, valid = residual_valid,
  lambda_component0 = 0)
summary(fit)
fdiagnostics(fit)
fitted_model <- fitted(fit)
fitted_bridge <- do.call(logLik, c(list(object = fitted_model,
  inter_arrival = path_2d$inter_arrival, type = path_2d$type), finitial_state(fit)))
fitted_state <- if (has_kernel_api) do.call(logLik, c(list(object = fitted_model,
  inter_arrival = path_2d$inter_arrival, type = path_2d$type, backend = "state"),
  finitial_state(fit))) else NULL
c(optimized = as.numeric(logLik(fit)), bridge = as.numeric(fitted_bridge),
  state = if (has_kernel_api) as.numeric(fitted_state) else NA_real_)
stopifnot(fdiagnostics(fit)$optimizer_success,
  isTRUE(all.equal(as.numeric(logLik(fit)), as.numeric(fitted_bridge), tolerance = 1e-10)),
  is.null(fitted_state) || isTRUE(all.equal(fitted_bridge, fitted_state, tolerance = 1e-10)))

The moving transition of tzexp can make the likelihood nonsmooth at the estimate. A successful optimizer code does not validate Hessian-based standard errors. ffit() marks Wald covariance unavailable when the optimizer curvature is invalid. Profile likelihood and bootstrap intervals require separate validation.
